TOA-DKK MM-41DP-EC เครื่องวัดค่านำไฟฟ้า | 1 Channel

MM-41DP-EC ฟังก์ชั่นการวัด

เครื่องวัดคุณภาพน้ำ ค่านำไฟฟ้าและความเค็ม 1 Channel

MM-41DP-EC จุดเด่น

สำหรับงานวัดคุณภาพน้ำตามลักษณะงานของผู้ใช้งาน

สะดวกด้วยหน้าจอแสดงผลแบบ LCD ขนาดใหญ่

สามารถแสดงค่าการวัดได้ถึง 2 ค่าพร้อมกัน

มีฟังก์ชั่นบันทึกข้อมูล 1,500 ค่า

มีฟังก์ชั่นชดเชยอุณหภูมิอัตโนมัติ ATC และแบบ Manual

มีฟังก์ชั่น Hold ค้างหน้าจอ

สามารถเชื่อมต่อ RS232C interface

ตัวเครื่องกันน้ำมาตรฐาน IP67
มาพร้อมกับโพรบวัดค่านำไฟฟ้า (MM4-EC) แบบกันน้ำ ความยาวสาย 1 เมตร

MM-41DP-EC ช่วงการวัด

Measurement Item/ Range

pH pH 0.000 to pH 14.000
mV (ORP) -2000 to 2000 mV
Conductivity 0.1 mS/m to 10 S/m
Resistivity 0.1 Ωm to 10kΩm (converted from Conductivity)
Salinity (NaCl, PSSs: Practical Salinity)TDS (total dissolved solid) Conversion from Conductivity
DO/ Saturation 0.00 to 20.00 mg/L or 0.0 to 200.0%
Temperature 0.0 to 100.0ºC when using DO probes: 0.0 to 50.0ºCMM-41DP-EC Power Supply

Display Range

pH pH -2.000 to pH 16.000
mV (ORP) -2200 to 2200 mV

Conductivity (manual/ automatic range switching)

0.000 to 2.000 mS/m (0.00 to 20.00 µS/cm)
0.00 to 20.00 mS/m (0.0 to 200.0 µS/cm)
0.0 to 200.0 mS/m (0.000 to 2.000 mS/cm)
0.000 to 2.000 S/m (0.00 to 20.00 mS/cm)
0.00 to 20.00 S/m (0.0 to 200.0 mS/cm)
Switchable between SI unit (S/m) and old unit (S/cm)

Resistivity (manual/ automatic range switching)

0.005 to 2.000 Ωm (0.5 to 200.0 Ωcm)
0.00 to 20.00 Ωm (0.000 to 2.000 kΩcm)
0.0 to 200.0 Ωm (0.00 to 20.00 kΩcm)
0.000 to 2.000 kΩm (0.0 to 200.0 kΩcm)
0.00 to 20.00 kΩm (0.000 to 2.000 MΩcm)
0.0 to 200.0 kΩm (0.00 to 20.00 MΩcm)
0.000 to 2.000 MΩm (0.0 to 200.0 MΩcm)
Switchable between SI unit (Ωm) and old unit (Ωcm)

Salinity 0.00 to 4.04% (NaCl) 0.00 to 42.40 psu (PSS)

TDS (total dissolved solid) (manual/ automatic range switching)

0 to 99.99 / 999.9 mg/L
0 to 9.999 / 99.99 / 999.9 g/L

DO/ Saturation 0.00 to 22.00 mg/L or 0.0 to 220.0%
Temperature -5.0 to 110.0ºC When using DO probes: -5.0 to 55.0ºC

Repeatability (instrument body)

pH ±0.006 pH
mV (ORP) ±2 mV

Conductivity/ Resistivity Salinity/ TDS (total dissolved solid)  ±0.5 %FS

DO/ Saturation When combined with 8 mg/L ±0.1 mg/L or 100% ±1% *MM4-DDO
Temperature Within ±0.2°C

MM-41DP-EC Power Supply

0.2 VA (with battery 3V), 0.9 VA (with USB-powered)

MM-41DP-EC ขนาดสินค้า

Approx. 70 x 35 x 185 mm
Approx. 290 g

MM-41DP-EC อุปกรณ์ที่มาในชุด

Main unit x 1
Conductivity probe (MM4-EC) x 1
Battery alkaline AA x 2
Operation manual

MM-41DP-EC ข้อมูลจำเพาะ

pH Temperature Compensation Range

ATC (Automatic Temperature Compensation): 0 to 100.0ºC
MTC (Manual Temperature Compensation): 0 to 100.0ºC

Conductivity Temperature Compensation scope

ATC (Automatic Temperature Compensation): 0 to 100.0ºC
MTC (Manual Temperature Compensation): 0 to 100.0ºC
OFF (No Temperature Compensation)

Conductivity Standard Temperature Setting  Fixed at 25ºC
Conductivity Temperature Coefficient (Linear) 0 to 10.00 %/ºC

DO Temperature Compensation range ATC (Automatic Temperature Compensation): 0 to 50.0ºC

pH calibration

JIS pH standard solution, US standard solution up to 5-point calibration or custom-made standard solution up to 2-point calibration
Temperature Calibration One-point calibration
Performance Guaranteed Temperature, Humidity

0 to 45ºC, 20 to 90% (non-condensing) * 0 to 40ºC when the optional External Printer is used

Waterproof structure

IP67 (1m, immersion allowed for 30 minutes) * Disabled when probes are not connected
Data Memory
MM-42DP: each ch 1500 data (measurement times, measurement values, Temprature)
(When Data Memory is operated, the measured data f ch1 and ch2 are memorized simultaneously)
MM-41DP: 1500 data (measured time, measured value, Temperature)

Calibration History Creation Function

Main unit side: Last 1 time
Probe side: pH is 10 batches including the newest, and DO is 8 batches including the newest

Interval Measurement function *¹

Setting interval: 1 second to 99 minutes 59 seconds or 5 minutes to 99 hours 59 minutes can be arbitrarily set
Print Function Can be connected to optional External Printer EPS-P30 (Plain Paper Print)

Auto Hold Function Stable judgment value: Fixed
Auto Power Off

OFF/ 10 min./ 30 min./ 60 min./ 180 min./ 360 min./ 720 min. settable

USB (peripheral, Micro) 1 port standerd equipment (isolated)

Analog output (insulate)*²

pH pH 0 to 14 > 500 to 1900 mV
mV (ORP) -2000 to 2000 mV > 200 to 2200 mV
Conductivity/ Resistivity Each range 0 to FS (2000 digit) > 200 to 2200 mV

Salinity (NaCl equivalent)  0.00 to 4.00% > 200 to 2200 mV

Salinity (PSS-78 equivalent)  0.00 to 40.00 psu > 200 to 2200 mV
TDS Each range 0 to FS (9999 digit) > 200 to 2200 mV
DO 0.00 to 20.00 mg/L > 200 to 2200 mV
Saturation 0 to 200% > 200 to 2200 mV
Temperature 0 to 100% > 200 to 2200 mV

Battery life (estimate)
*Backlight turns off, option not connected

When a pH or ORP probe is connected: Approx. 800 hours
When a Conductivity probe is connected: Approx. 500 hours
When an optical DO probe is connected: Approx. 60 hours

*¹ It is effective for simplified monitoring in a short time (about half a day), etc.
*² The use of AC-USB adapter ASSY (7472510K) is recommended for optional analogue-output connections and for continuous-measurement with DO probes because battery life is shortened (USB-powered).
