Mitcorp MITC-39D4W-F-1.5M-TU-M โพรบขนาด 3.9mm ยาว 1.5m ปรับทิศทางได้ 360 องศา สำหรับกล้องส่องท่อรุ่น X2000

MITC-39D4W-F-1.5M-TU-M | ขนาดและความความยาวของหัวโพรบ

• Probe head diameter: 3.9 mm (O.D. Tolerance: ±0.15 mm)
• Probe head length: 13 mm

MITC-39D4W-F-1.5M-TU-M | ทิศทางของโพรบ

Front view

Articulation angle: 360° Articulation Probes full ways ≥140°

MITC-39D4W-F-1.5M-TU-M | ความยาวโพรบ

1.5 m

MITC-39D4W-F-1.5M-TU-M | ความละเอียด

Still image resolution (.jpg): 1600*1600

Video resolution (.mov): 1600*1600

MITC-39D4W-F-1.5M-TU-M | อุณหภูมิที่สามารถใช้งานได้

In air: -10~-100°C ; In water: 10~30°C

MITC-39D4W-F-1.5M-TU-M | ความทนทานต่อเหลว

Operable when exposed to machine oil, light oil, or 5% saline solution

MITC-39D4W-F-1.5M-TU-M | ข้อมูลจำเพาะ

• Probe head diameter: 3.9 mm (O.D. Tolerance: ±0.15 mm)
• Probe head length: 13 mm
• Direction of view: Front
• Illumination: Front LED
• Field of view (FOV): 120°
• Depth of Field (DOF): 5 mm~100 mm
• Still image resolution (.jpg): 1600*1600
• Video resolution (.mov): 1600*1600
• Articulation angle:  full ways ≥140° (The maximum articulation angle may degrade over time)
• Probe length: 1.5 m
• Operating temperature: In air: -10~-100°C ; In water: 10~30°C
• Probe head material: Stainless Steel
• Probe material: Tungsten braid
• Joystick console dimensions: (WxDxH) 139.4x193x84.2 mm (w/o SR and insert tubes)
• Joystick console buttons: Brightness+, Brightness-, snapshot/record
• Lock and move: Joystick/Unlock switch on console
• Dust and water proof: Joystick console: IP54 ; Insert Tube: under water 1 m for 30 minutes
• Relative humidity: Max 95% non-condensing
• Liquid resistance: Operable when exposed to machine oil, light oil or 5% saline solution
• Storage temperature: -10°C~70°C
• Rigid sleeve: OD: 8 mm/ID: 7 mm Protection: OD: 10 mm Extension joint ring: OD: 11.2 mm
• Trolley case: Grip material: Rubber/Aluminum/Plastic; Tube material: Stainless steel, HDPE EVA with storage reel
