Image Streaming configuration (FLIR A50/A70) For use with FLIR’s A50 or A70 Thermal Camera Cores (sold separately), the FLIR Image Streaming Configuration provides camera control, image streaming over Ethernet, and compatibility with software applications designed for raw thermal data collection.
Index
T300390 ฟังก์ชั่นการวัด
- Designed for use with FLIR’s A50 or A70 Thermal Camera Cores
- Provides camera control capabilities
- Image streaming over Ethernet
- Analytics
- Compatible with software applications designed for raw thermal data collection
- GigE Vision and GenICam compatible: enables camera control and visual/ thermal streaming into third-party machine vision applications
- Full support for compressed radiometric streaming using FLIR Atlas SDK (Advanced Configuration ONLY)
- Simple integration using non-proprietary industry-standard connectivity
- Optimise process control and quality assurance to improve yield, product quality, efficiency, and cost-effectiveness
T300390 อุปกรณ์ที่มาในชุด
Unit x1
T300390 ข้อมูลจำเพาะ
Image & Optical Data Advanced Configuration
IR resolution 464 × 348 (A50), 640 × 480 (A70)
Visual Resolution 1280 × 960 pixels (optional)
Thermal Resolution
A70: 29°: <45 mK, 51°: <45 mK, 95°: <60 mK
A50: 29°: <35 mK, 51°: <35 mK, 95°: <45 mK
Focus Fixed, adjustable with included focus tool
Spatial Resolution (IFOV)
A50: 29°: 1.2 mrad/pixel, 51°: 2.1 mrad/pixel, 95°: 4.0 mrad/pixel
A70: 29°: 0.84 mrad/pixel, 51°: 1.5 mrad/pixel, 95°: 2.9 mrad/pixel
FOV Options 29°, 51°, 95°
Detector Pitch A50: 17 µm, A70: 12 µm
Spectral Range 7.5–14.0 µm
Frame Rate 30 Hz
Ethernet Communication GigE Vision, GenICam (SFNC 2.4)
Connector Types M12 8-pin X-coded, female; RP-SMA, female
Ethernet Interface Wired, Wi-Fi (optional)
Ethernet Power Power over Ethernet, PoE IEEE 802.3af class 3
Ethernet Protocols
IEEE 1588, SNMP, TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP,
sftp (server), FTP (client), SMTP, DHCP, MDNS (Bonjour), uPnP
Ethernet Standard IEEE 802.3
Ethernet Type 1000 Mbps
Digital Input/Output
Connector Type M12 Male 12-pin A-coded (shared with external power)
Digital Input 2× opto-isolated, Vin (low) = 0 to 1.5 V, Vin (high) = 3 to 25 V
Digital Output
3× opto-isolated, 0 to 48 V DC, max. 350 mA (derated to 200 mA
at 60°C). Solid-state opto relay, 1× dedicated as fault output (NC)
Power
Power Consumption
7.5 W at 24 V DC typical, 7.8 W at 48 V DC typical,
8.1 W at 48 V PoE typical
External Power Operation 24/48 V DC 8 W max
External Voltage Allowed range 18 V to 56 V DC
Power Connection M12 12-pin A-coded, male (shared with Digital I/O)
