IMADA ZTA-5N เครื่องวัดแรงดึง/แรงผลัก (5N)

ZTA-5N ฟังก์ชั่นการวัด

เครื่องวัดแรงดึง/แรงผลักแบบดิจิตอล

ZTA-5N จุดเด่น

• High sampling rate (2000Hz) for accurate results, capturing small changes and accurate peak values by following rapid changes of force
• Reduces risk of misreading values with easy-to-read high luminance organic EL display. Allows customers to customize the contents for the three sections of the display screen
• Improves testing versatility by various data output options such as USB, wireless, and serial communication, which allows data management on a PC and combination with external devices
• Allows easy data acquisition and management with the included USB cable and software. By using with optional software real-time force-time/force-displacement graphing also possible
• Equips additional functions such as displacement I/O (linear scale required), direct connection to USB flash drive, and 1st and 2nd peak value detection

ZTA-5N ช่วงการวัด

5N
Display  :  5.000N (5000mN)
Resolution  : 0.001N (1mN)
Accuracy : +/-0.2%F.S.+/-1digit

ZTA-5N Power Supply

AC adapter

ZTA-5N ขนาดสินค้า

Weight : Approx.490g (*The Weight differs according to the Model range.)

ZTA-5N อุปกรณ์ที่มาในชุด

AC adapter

Inspection certificate

CD driver (including data logging software)

Attachments(The set of attachments varies according to range.)
Handles (only for 2500N/5000N range)

USB cable

Carrying case

Adaptor for USB flashdrive (*USB flash drive is not included.)

ZTA-5N ข้อมูลจำเพาะ

Feature Standard Model with high functionality and usability.
Measurement Unit N, kgf, lbf (*1)
Display 4-digit Organic EL
Display update 16 / sec
Sampling Rate 2000 data / sec at maximum (*2)
Battery 6.5 hours (2 hours for re-charging) (*3)
Safe overload rating Approx.200%F.S.
Operating environment Temperature: 0 to +40 degree Celsius, Humidity: 20 to 80%RH

Function

Customized display (header and footer), Peak hold (tension and compression), Internal
1000 points data memory, Comparator (judgment of OK or NG), Reversible display, Sign
inversion, Zero clear timer, +NG alarm, Off timer (auto power off), Dumping, Time display,
1st/2nd peak, Displacement detection at force peak value,
Displacement zero reset at selected force, Setting lock

Output

USB, RS232C / ±2VDC analog output (D/A),
Comparator 3 steps (-NG/OK/+NG), Overload alarm
Overload warning Approx.110%F.S. (Warning message and alarm)
External connecting switch Power ON / OFF / Send and Hold / Zero reset / Peak and Real-time switching

Available linear scales (*4)

- Online driver output (a line receiver according to RS422/485 must be built in.)
- Open collector output (Voltage drop between contacts must be smaller than 0.5V.)

*1 The measurement Unit: mN displayed for models of 5N or less, and kN displayed for models of 1000N or more.
In addition, possible to display the unit kg (g: 5N or less range) as a conversion value.
*2 Up to 100 data/sec. is saved in USB memory (selectable among 1, 50, and 100 /sec).
*3 The battery is more consumed when connected to USB flash drive or a linear scale.
*4 Some linear scales could not be available even if they meet the mentioned specifications.
*5 The Weight differs according to the Model range.
*6 USB flash drive is not included.
