LOAD CELL ทรานสมิตเตอร์ ใช้ได้กับโหลดเซลล์ 1 to 2 mV/V Variable exciting voltage DC 4 to 12V ในชุดไม่รวม LOAD CELL Sensor (เซนเซอร์แยกจำหน่าย) ส่งสัญญาณ Output: 4 to 20 mA, DC. ยี่ห้อ Lutron
TR-LDT1A4 ฟังก์ชั่นการวัด
Load Cell ทรานสมิตเตอร์
TR-LDT1A4 จุดเด่น
Versatile Measurement Range: Suitable for load cells with a measurement range of 1 - 2 mV/V and variable exciting voltage from DC 4V to 12V, providing flexibility for different load cell types.
Standardized Output: Delivers a 4-20 mA output signal where 0 weight corresponds to 4 mA, 1/2 weight corresponds to 12 mA, and full-scale weight corresponds to 20 mA, ensuring standardized data output for easy integration.
User-Friendly Adjustments: Features external ZERO and SPAN VR adjustments, allowing for easy calibration and fine-tuning of measurements to ensure accuracy.
Robust Power Supply: Operates with a wide power supply range of 90 to 260 ACV, 50/60 Hz, ensuring reliable performance in various power conditions.
Durable and Flexible Design: Suitable for DIN rail or wall mounting, providing flexibility in installation and ensuring durability in various industrial environments.
TR-LDT1A4 ช่วงการวัด
Measurement Range: 1 - 2 mV/V
Exciting Voltage: Variable DC 4V - 12V
Output Signal:
4 - 20 mA
0 weight = 4 mA
1/2 weight = 12 mA
Full-scale weight = 20 mA
TR-LDT1A4 Power Supply
90 - 260 ACV, 50/60 Hz
TR-LDT1A4 อุปกรณ์ที่มาในชุด
Load cell is optional.
TR-LDT1A4 อุปกรณ์เสริม
200 g load cell
2 Kg load cell
5 Kg load cell
100 Kg load cell
150 Kg load cell
TR-LDT1A4 ข้อมูลจำเพาะ
Adjustment: External ZERO and SPAN VR adjustments
Operating Temperature 0 - 50 °C /32 - 122 °F
Operating Humidity Less than 80 %RH
Mounting: DIN rail or wall mounting
Connection: Four wires
