FLUKE-15BPLUS ฟังก์ชั่นการวัด
Maximum voltage between any terminal and earth ground : 1000 V
Display (LCD) : 4000 counts, updates 3/sec
Backlight
FLUKE-15BPLUS ช่วงการวัด
AC volts (40 Hz to 500 Hz) : 1000 V
DC volts : 1000 V
Diode test : 0-2.000 V
Resistance (Ohms) : 0.1- 40.00 MΩ
Capacitance : 0.01-1000 μF
Frequency : 0.01-100.0 kHz
FLUKE-15BPLUS Power Supply
Battery type : 2 AA, NEDA 15 A, IEC LR6
Battery life : 500 hours minimum (50 hours in LED Test mode without load. The hours with load depends on the type of LED under test.)
FLUKE-15BPLUS ขนาดสินค้า
Size (HxWxL) : 183 mm x 91 mm x 49.5 mm
Weight : 455 g
FLUKE-15BPLUS อุปกรณ์ที่มาในชุด
-Test leads with caps
-2 AA battery
-user manual
FLUKE-15BPLUS อุปกรณ์เสริม
-TPAK Meter Hanging Kit
-TL175 TwistGuard™ Test Leads
FLUKE-15BPLUS ข้อมูลจำเพาะ
-Accuracy is specified for 1 year after calibration, at operating temperatures of 18 °C to 28 °C, relative humidity at 0 % to 75 %. Accuracy specifications take the form of: ± ([% of Reading] + [Number of Least Significant Digits]).
-Temperature Operating: 0 °C to 40 °C; Storage: -30 °C to 60 °C
-Relative humidity Operating humidity: ≤ 90 % RH at 10 °C to 30 °C; ≤ 75 % RH at 30 °C to 40 °C; non-condensing (<10 °C)
-Fuse protection for current inputs : 440 mA, 1000 V fast fuse, Fluke specified part only. 11 A, 1000 V fast fuse, Fluke specified part only
-IP rating : IP40
-Safety : IEC 61010-1, IEC61010-2-030 CAT III 600 V, CAT II 1000 V, Pollution Degree 2
