Fluke-754 Documenting Process Calibrator-HART

Fluke-754 ฟังก์ชั่นการวัด

Documenting Process Calibrator-HART ฟังก์ชั่น HART สำหรับงานคาลิเบรท, maintaining

Fluke-754 จุดเด่น

Complete pressure, temperature, and mA loop calibrator
Troubleshoot and calibrate HART smart digital transmitters
Create calibration procedures and automatically document results
Connect to calibration management software

Fluke-754 ช่วงการวัด

Measurement Accuracy

Voltage DC Range/ Resolution

100.000 mV 0.02% + 0.005 mV (1 Year) 0.03% + 0.005 mV(2 Year)
3.00000 V    0.02% + 0.00005 V (1 Year) 0.03% + 0.00005 V(2 Year)
30.0000 V    0.02% + 0.0005 V(1 Year)    0.03% + 0.0005 V(2 Year)
300.00 V    0.05% + 0.05 V(1 Year)        0.07% + 0.05 V(2 Year)

Voltage AC Range/ Resolution

3.000 V (40 Hz to 500 Hz) / 0.001 V  0.5% + 0.002 V(1 Year)   1.0% + 0.004 V(2 Year)
30.00 V (40 Hz to 500 Hz) / 0.01 V  0.5% + 0.02 V(1 Year)    1.0% + 0.04 V(2 Year)
300.0 V (40 Hz to 500 Hz) / 0.1 V      0.5% + 0.2 V(1 Year)      1.0% + 0.2 V(2 Year)

Current DC Range/ Resolution

30.000 mA    0.01% + 5 uA(1 Year)   0.015% + 7 uA(2 Year)
110.00 mA    0.01% + 20 uA(1 Year) 0.015% + 30 uA(2 Year)

Resistance Range/ Resolution

10.000 Ω    0.05% + 50 mΩ(1 Year)    0.07% + 70 mΩ(2 Year)
100.00 Ω    0.05% + 50 mΩ(1 Year)    0.07% + 70 mΩ(2 Year)
1.0000 kΩ    0.05% + 500 mΩ(1 Year) 0.07% + 0.5 Ω(2 Year)
10.000 kΩ    0.1% + 10 Ω(1 Year)        0.15% + 15 Ω(2 Year)

Frequency Range/ Resolution

1.00 to 110.00 Hz / 0.01 Hz              0.05 Hz(2 Year)

110.1 to 1100.0 Hz / 0.1 Hz              0.5 Hz(2 Year)

1.101 to 11.000 kHz / 0.001 kHz     0.005 kHz(2 Year)

11.01 to 50.00 kHz / 0.01 kHz         0.05 kHz(2 Year)

Source Accuracy

Voltage DC

100.000 mV 0.01% + 0.005 mV(1 Year)    0.015% + 0.005 mV(2 Year)
1.00000 V    0.01% + 0.00005 V(1 Year) 0.015% + 0.0005 V(2 Year)
15.0000 V    0.01% + 0.0005 V(1 Year)    0.015% + 0.0005 V(2 Year)

Current DC

22.000 mA (source)      0.01% + 0.003 mA(1 Year)    0.02% + 0.003 mA(2 Year)
Current sink (simulate) 0.02% + 0.007 mA(1 Year) 0.04% + 0.007 mA(2 Year)

Resistance

10.000 Ω  0.01% + 10 mΩ(1 Year) 0.015% + 15 mΩ(2 Year)
100.00 Ω  0.01% + 20 mΩ(1 Year) 0.015% + 30 mΩ(2 Year)
1.0000 kΩ  0.02% + 0.2 Ω(1 Year)    0.03% + 0.3 Ω(2 Year)
10.000 kΩ  0.02% + 3 Ω(1 Year)        0.03% + 5 Ω(2 Year)

Frequency

0.1 to 10.99 Hz                0.01 Hz(2 Year)

0.01 to 10.99 Hz              0.01 Hz(2 Year)

11.00 to 109.99 Hz         0.1 Hz(2 Year)

110.0 to 1099.9 Hz       0.1 Hz(2 Year)

1.100 to 21.999 kHz  0.002 kHz(2 Year)

22.000 to 50.000 kHz  0.005 kHz(2 Year)

Fluke-754 Power Supply

Internal Battery Pack Li-ion: 7.2V,4400mAh, 30 Wh

Fluke-754 ขนาดสินค้า

136 x 245 x 63 mm (5.4 x 9.6 x 2.5 in)
1.2 kg (2.7 lb)

Fluke-754 อุปกรณ์ที่มาในชุด

Three sets of stackable test leads

three sets of TP220 test probes with three sets of “extended tooth” alligator clips

two sets AC280 hook clips

BP7240 Li-ion battery pack,

BC7240 battery charger

C799 field soft case

USB communication cable,
getting started guide

instruction manual and instruction videos on CDROM

traceable certificate of calibration

DPC/TRACK 2 sample software that enables upload and printing of calibration records.

Model Fluke-754 includes HART communication cable. Includes C799 Field Soft Case

Fluke-754 ข้อมูลจำเพาะ

Data log functions

Measure functions Voltage, current, resistance, frequency, temperature, pressure

Reading rate 1, 2, 5, 10, 20, 30, or 60 readings/minute
Maximum record length  8000 readings (7980 for 30 or 60 readings/minute)

Ramp functions Source functions Voltage, current, resistance, frequency, temperature

Rate 4 steps/second

Trip detect   Continuity or voltage (continuity detection not available when sourcing current)

Loop power function

Voltage Selectable, 26 V
Accuracy 10%, 18 V minimum at 22 mA
Maximum current 25 mA, short circuit protected
Maximum input voltage 50 V DC

Step functions

Source functions Voltage, current, resistance, frequency, temperature
Manual step Selectable step, change with arrow buttons
Autostep Fully programmable for function, start delay, stepvalue, time per step, repeat

Environmental Specifications

Operating temperature -10°C to +50°C
Storage temperature -20°C to +60°C
Dust/water resistance Meets IP52, IEC 529
Operating altitude 3000 m above mean sea level (9842 ft)

Safety Specifications

Agency approvals CAN/CSA C22.2 No 1010.1-92, ASNI/ISA S82.01-1994, UL3111, and EN610-1:1993

Battery life >8 hours typical
Battery replacement Replace without opening calibrator; no tools required
Side port connections

Pressure module connector
USB Connector to interface to your PC
Digital instrument (HART) connector
Connection for optional battery charger/eliminator
Data storage capacity 1 week of calibration procedures results
90 day specifications

The standard specification interval for the 750 Seriesare 1 and 2 years.
Typical 90 day measurement and source accuracy can be estimated by dividing the one year "% of reading" or "% of output" specifications by 2.
Floor specifications, expressed as "% of full scale" or "counts" or "ohms" remain constant.
