Anritsu 619K-010-TC1-ASP High temperature probes

ฟังก์ชั่นการวัด

วัดอุณหภูมิสูง

ช่วงการวัด

Temp. range -50 to 1200°C Tolerance

0°C ≦ t ≦ 100°C : ±2.5°C 100°C < t ≦ 200°C : ±3.8°C 200°C < t ≦ 300°C : ±5.0°C 300°C < t ≦ 400°C : ±6.3°C 400°C < t ≦ 500°C : ±7.5°C 500°C < t ≦ 700°C : ±(0.015×| ｔ |)°C 700°C < t ≦ 800°C : ±(0.02×| ｔ |)°C * t : Measured temperature

ขนาดสินค้า

สายยาว 1 เมตร

อุปกรณ์ที่มาในชุด

โพรบ 619K-010-TC1-ASP x1

ข้อมูลจำเพาะ

Response time 15s

Remarks * The operating temperature limit is determined by the allowable temperature limit of the probe head contacts the measurement target. * Note that the operating temperature limit is not the same as the allowable temperature limits of the grip,cable,and plug. * The response time is the time required to detect 99% of the true value on a flat and smooth metal surface. * Number of contacts enabling measurement within the tolerance range on a flat and smooth metal surface at a temperature of 300°C

(or at the operating temperature limit if the operating temperature limit is below 300°C). * Please contact the distributor for price and delivery.
