Shimpo รุ่น EE-1B เครื่องวัดความเร็วรอบแบบสัมผัส
ee-1b
฿9,000.00(ราคายังไม่รวมภาษี 7%)
จำนวน
สินค้าใกล้หมดแล้ว
เครื่องวัดความเร็วรอบแบบสัมผัส Contact Type ช่วงการวัด 1.0 to 25,000rpm บันทึกค่าได้ 10 ค่า , ดูค่าสูงสุด ต่ำสุดของการวัดได้ ออกแบบกะทัดรัด ขนาดพอดีฝ่ามือ ให้การวัดที่มีความเสถียร ยี่ห้อ Shimpo, Japan
Shimpo รุ่น EE-1B เครื่องวัดความเร็วรอบแบบสัมผัส
ออกแบบกะทัดรัด ขนาดพอดีฝ่ามือ ให้การวัดที่มีความเสถียร
แบบสัมผัส (Contact type): วัดโดยนำหัววัดสัมผัสโดยตรงกับจุดศูนย์กลางของแกนหมุนของชิ้นงานที่ต้องการวัด
Specifications
Model | EE-1B (Contact type | |
Measurement method | Put the contact against the center of revolution axis | |
Display | 5 digits display LCD Font height: 12mm | |
Measurement range
| Revolution speed | 1.0 to 25,000rpm |
0.02 to 416.67rev/sec | ||
Peripheral speed (contact) (type-6 foil attached)
| 0.3 to 6350.0cm/sec | |
0.001 to 63.500m/sec | ||
0.2 to 3810.0m/min | ||
0.003 to 228.60km/h | ||
Length (contact) (type-6 foil attached)
| 1 to 99,999cm | |
0.01 to 99,999m | ||
0.0001 to 99,999km | ||
Total number of rotations | 0.1 to 99,999rev | |
Measurement accuracy | 1.0 to 599.9rpm: ±1rpm | |
Measurement time | Less than 4rpm: max. 10 seconds 4rpm to 25,000rpm: Approx. 1 second | |
Memory | Maximum, minimum, latest measurement values, other 10 measurement values, and their average value | |
Power supply | AA dry cell battery (manganese or alkali) x 3 | |
Auto power off | 5 minutes | |
Accessories | Carrying case AA manganese dry cell battery x 3 Instruction manual Type-6 foil Funnel adapter Conical adapter | |
External dimensions | Length 122.5 x Width 64 x Thickness 31.5mm | |
Casing material | ABS resin | |
Weight (main unit) | Approx. 180g (including manganese dry cell batteries) | |
Operating temperature | 0°C to 40°C (No condensation) | |
