Useful for automated manufacturing lines as the magnetic force can be turned on and off or increased/decreased or operated remotely via a rectifier (to be installed additionally).
Features
Special cables that have especially high durability against bending and vibration are used. (Employed in all models except for KE-1B.)
Electrical control can be used for turning on and off the magnetic force and for remote operation.
Usable continuously.
Finished by plating
Model | Nominal Size | Max. Holding Power | Mounting | Power Cord | |||
M1 | M_{2} | P1 | C | P2 | |||
KE-1B | φ10(0.39) * 30(1.18) | 8N (0.8kgf) | M4 (0.15) ×0.7 (0.02) Depth 6 (0.23) | _ | _ | _ | _ |
KE-1.5B | φ 15(0.59) * 40(1.57) | 18N (1.8kgf) | |||||
KE-2B | φ 20(0.78) 40(1.57) | 28N (2.8kgf) | φ3.5(0.13) | 7 (0.27) | |||
KE-3B | φ* 30(1.18) * 40(1.57) | 180N ( 18kgf) | M6 (0.23) × 1.0 (0.03)Depth 12 (0.47) | φ * 4(0.15) Depth 2 (0.07) | 10 (0.39) | 8(0.31) | |
KE-4B | φ* 40(1.57) * 40(1.57) | 400N ( 40kgf) | φ * 4(0.15) Depth 3 (0.11) | 15 (0.59) | 8.5 (0.33) | ||
KE-5B | φ* 50(1.96) * 50(1.96) | 590N( 60kgf) | M8 (0.31) ×1.25 (0.04) Depth 15 (0.59) | φ * 5(0.19) Depth 4 (0.15) | 18 (0.70) | φ5.9(0.23) | 10(0.39) |
KE-6B | φ* 60(2.36) * 60(2.36) | 1080N (110kgf) | 20 (0.78) | 12(0.47) | |||
KE-7B | φ 70(2.75) 60(2.36) | 1470N (150kgf) | M10 (0.39) × 1.5 (0.05) Depth 15 (0.59) | φ * 6(0.23) Depth 6 (0.23) | 15(0.59) | ||
KE-8B | φ 80(3.15) 60(2.36) | 1960N (200kgf) | |||||
KE-9B | φ 90(3.54) 60(2.36) | 3230N (330kgf) | |||||
Model | Voltage | Current | Working Rate | Applicable Rectifier | Mass |
KE-1B | 6 VDC | 0.18A | 100% ED | KR-T101A-6/24 RH-M303A-6/24,-C1 ,C2 | 15g/0.03 lb |
KE-1.5B | 24 VDC | 0.08A | KR-T101A 6/24 RH-M303A-6/24、C1,C2 RH-M105B-24 | 35g/0.07 lb | |
KE-2B | 0.07A | 60g/0.13 lb | |||
KE-3B | 0.19A | 150g/0.33 lb | |||
KE-4B | 0.24A | 300g/0.66 lb | |||
KE-5B | 90 VDC | 0.12A | KR-N101A KR-N103A RH-M102C RH-M105B RH-M205B RH-M210B | 560g/1.23 lb | |
KE-6B | 0.19A | 1.0kg/2.20 lb | |||
KE-7B | 0.20A | 1.4kg/3.08 lb | |||
KE-8B | 0.26A | 1.7kg/3.74 lb | |||
KE-9B | 0.35A | 2.2kg/4.85 lb |
