HT ITALIA HT305 Reference Cell สำหรับการวัดความเข้มรังสีดวงอาทิตย์

Irradiation measurement

Range: 5 ÷ 100

Accuracy : ±(3.0%reading + 5W/m2)

Range: 101 ÷ 1400

Accuracy :±3.0%reading

Accuracy referred @ STC condition (1000W/m2, 25°C, AM=1.5)

EMC:

IEC/EN61326-1

Technical literature:

IEC/EN61187

Calibration:

IEC/EN60904-2

Pollution degree:

2

Type of photovoltaic cell:

Monocrystalline

Internal temperature sensor:

PT1000

Visual range:

≥160°

Output connector:

5-pole HT custom connector

Length of output cable:

approx. 2m

Dimensions (L x W x H):

111 x 85 x 28mm (4 x 3 x 1in)

Weight (with connection cable):

240g (8ounces)

Mechanical protection:

IP67 in compliance with IEC/EN 60529

Operating temperature:

-20°C ÷ 70°C (-4°F ÷ 158°F)

Oprating humidity:

<95%RH (10°C÷30°C) no condensation

<75%RH (30°C÷40°C) no condensation

<55%RH (40°C÷50°C) no condensation

Max height of use:

2000m (6562ft
