Anritsu A1-6-E-J1-M1-L300-TC1-ASP Sheathed temperature sensor
A1-6-E-J1-M1-L300-TC1-ASP
เป็นโพรบแบบ Sheath sensor ซึ่งสามารถดัดส่วน Sheath ให้เข้ากับตำแหน่งวัดได้ จึงเหมาะกับการวัด อุณหภูมิของของเหลว, อากาศ หรือภายในเตา/เครื่องจักร โดยเฉพาะพื้นที่ที่เข้าถึงยาก
สเปค
| ระยะเวลาจัดส่ง | จัดส่งภายใน 30 วัน |
|---|
คำถามที่พบบ่อย
มีข้อสงสัยเกี่ยวกับสินค้า/บทความ สอบถามชุมชนหรือผู้เชี่ยวชาญของเรา
Specifications
Parameter | Specifications |
Operating temperature range | -40 to 650°C |
Tolerance | 333°C to less than 650°C: 0.0075 × |t|°C -40°C to less than 333°C: ±2.5°C *|t| is a value expressed in temperature (°C) that is independent of the +/- sign of the measured temperature. |
Code type and length | For Type E: TC-E cord 1m |
Plug shape | For Type E: ASP-EM |
Types of thermal junctions | ground plane |
Sheath pipe material | SUS316 |
Standard resistance values | Type E: 19Ω |
Standard (manufacturer) calibration temperature range | -40 to 500°C |
JCSS calibration temperature range | This product has not undergone JCSS calibration. (However, calibration is possible for sheath lengths of 400mm or more.) |
repair | Unrepairable item |
Remark
The operating temperature range is the temperature range to which the sensor's temperature sensing part and guard can make contact.
The response speed indicates the time it takes to achieve a 99% response when measuring boiling water or boiling steam.
* The standard resistance value is the sum of the standard resistance values of the sheath and cord. Please ensure that this does not exceed the signal source resistance of the measuring instrument body.
* General (manufacturer) calibration is subject to a fee. For calibration below 0℃ or above 100℃, the insertion length (sheath length) must be 100mm or more, and for calibration above 500℃, the insertion length (sheath length) must be 400mm or more.
* JCSS calibration for this product is subject to a fee. Calibration requires that the insertion length be 400mm or more, that it is not curved, and that the total length of the sensor excluding the cord is 1500mm or less.
* Due to manufacturing processes, the production lead time may be longer than stated, so please consider this as an estimate.
* Please contact us if you have any questions regarding price, etc.
* Using sheath-type sensors to measure molten metal will significantly reduce their durability and may cause them to break easily, so please do not use them to measure molten metal.
