Anritsu CS-11E-010-1-TC1-ASP โพรบวัดอุณหภูมิ Micro Surface Temperature Sensor

Temp. range

-50°C to 400°C

Tolerance

-50 to 100°C: ±2.5°C

Above 100 to 200°C: ±3.1°C

Above 200 to 300°C: ±5.0°C

Above 300 to 400°C: ±6.3°C

Response time

2 s

Operating Temperature Range

-50 to 400°C

Accuracy

-50 to 100°C: ±2.5°C

Above 100 to 200°C: ±3.1°C

Above 200 to 300°C: ±5.0°C

Above 300 to 400°C: ±6.3°C

Response Time

2 seconds

Durability

More than 50,000 contacts

Cable Type & Length

Type E: TC-E compensation cable, 1 m

Type K: TC-K compensation cable, 1 m

Connector Type

Type E: ASP-E-M

Type K: ASP-K-M

Standard (Manufacturer) Calibration Range

-50 to 400°C

JCSS Calibration

JCSS calibration is not available for this product.
