Mitutoyo M-103-138 ไมโครมิเตอร์วัดนอก 25-50mm (0.01mm)

Range:

25 - 50 mm

Accuracy:

±2 µm

Flatness:

0,6 μm

Mass:

215 g

Measuring surfaces:

Carbide-tipped, micro-lap finish

Parallelism:

(2+L/100) μm, L = max. range (mm)

Digital/Analog:

Analog

Graduation:

0,01 mm

Scale:

Thimble and sleeve satin chrome finish, ø18 mm

Measuring spindle:

With spindle lock, ø6,35 mm , spindle pitch 0,5 mm

Remarks:

Ratchet Stop

Measuring force:

5 - 10 N

Delivered:

Including box, setting standard, key, certificate of inspection

Inch-Metric:

Metric
