FLIR-MR176 เครื่องวัดความชื้น│IGM™ Moisture Meter

รหัสสินค้า

MR176

฿44,800.00(ไม่รวมภาษี)

จำนวน

สินค้าใกล้หมดแล้ว

ภาพรวม

FLIR MR176 ด้วยเทคโนโลยีอินฟราเรดนำทาง (IGM) ที่ขับเคลื่อนโดยเซ็นเซอร์ภาพความร้อน จะสามารถนำไปจุดที่แม่นยำซึ่งอาจจะมีความชื้นซ่อนอยู่ ใช้เลเซอร์เป้าเล็งในตัว เพื่อช่วยระบุตำแหน่งพื้นผิวของปัญหาที่พบ เซ็นเซอร์แบบไม่มีพินในตัวและหัววัดแบบพินภายนอกให้ความยืดหยุ่นในการวัด แถมยังเพิ่มความสะดวกอีกด้วย

เพิ่มคำถาม

MR176 ฟังก์ชั่นการวัด

วัดความชื้น

MR176 จุดเด่น

  • สะดวก ยืดหยุ่น ใช้งานง่าย
  • เมนูใช้งานง่าย แบ่งปันการอ่านรูปภาพ
  • สร้างรายงานอย่างรวดเร็วด้วยซอฟแวร์ FLIR Tools

MR176 ช่วงการวัด

Range : 7% to 30% / Accuracy ±1.5% MC

Range : 30% to 100% / Accuracy : Reference only

FLIR-MR176 เครื่องวัดความชื้น│IGM™ Moisture Meter

MR176 Power Supply

3.7V, 3000mAh Li-ion rechargeable via micro USB

MR176 ขนาดสินค้า

33x14x12cm.

MR176 ข้อมูลจำเพาะ

Thermal image palettes : Iron, Rainbow, Ice, Greyscale

Pin Moisture Groups : 9 Material Groups

Air Temperature : Range 32 to 122°F (0 to 50°C) / Basic Accuracy ±1.1°F (±0.6°C)

Relative Humidity : Range 0 to 100% / Basic Accuracy 2.5%RH

Dew Point : Range -22 to 122°F (-30 to 50°C) / Basic Accuracy ±1.8°F (±1.0°C)

Includes : MR01 Replaceable Temperature and Relative Humidity Sensor, MR02 Standard Pin Probe, Quick Start Guide,International USB Charger, USB Cable


IMAGING & OPTICAL

Display Type : QVGA (320 x 240 pixel) 2.3" color TFT graphical display

Field of View [W x H] : 51° × 38°

Gallery : 17540

Image Update Speed Frequency : 9Hz

Imaging Detector : FLIR Lepton microbolometer

Laser Orientation : Single laser pointer to center of thermal image

Sensitivity : <150mK

Spectral Response : 8 to 14µm

Thermal image minimum focus distance : 4" (10cm)

Thermal image palettes : Iron, Rainbow, Ice, Greyscale

Thermal Image Resolution [W x H] : 4800 pixels (80 × 60)


MEASUREMENT & ANALYSIS
Detection Limit : 19.7in2 (49cm2) (Wet Area Detection @ 32ft (10m)

Image Calibration : Automatic with manual lock scale option

Measurement Resolution : 0.1

Pinless Moisture Range : 0 to 100

Response Time Pin Mode : 750ms

Response Time Pinless : 100ms


COMMUNICATION & DATA STORAGE
Saved Image File format : BMP with measurement values overlaid

Stored Image Capacity : 9999 images


POWER
Continuous Run Time : 18 hours max

Typical Usage : 4 work weeks


ENVIRONMENTAL & CERTIFICATIONS

Agency Approvals : CE, FCC Class B, RCM

Certification Standards : EN 61326 (EMC), EN 60825-1 Class 2 (Laser)

Mixing Ratio : Range 0 to 560GPP (0.0 to 80.0 g/kg) / Basic Accuracy ±2GPP (0.25 g/kg)

Relative Humidity : Range 0 to 100% / Basic Accuracy 2.5%RH

Vapor Pressure : Range 0.0 to 12.0kPa / Basic Accuracy ±0.05kPa

Warranty : 10 year
