AD-8127 Multi-functional compact printer for balances/scales
ad-8127
฿24,800.00(ราคายังไม่รวมภาษี 7%)
AD-8127 เป็นเครื่องพิมพ์ที่ออกแบบมาสำหรับใช้งานร่วมกับเครื่องชั่งอิเล็กทรอนิกส์ A&D เครื่องชั่งนับจำนวน เครื่องชั่งน้ำหนัก เครื่องวิเคราะห์ความชื้น และ/หรือเครื่องแสดงผลน้ำหนัก ใช้เทคโนโลยีการพิมพ์แบบดอทเมทริกซ์
Features
Easy setting and operation with a numeric keypad and LCD display
Built-in calendar and clock for printing date and time at any time
Sends re-zero and weighing data request commands to the balance/scale
Clear and visible dot matrix printing, which also enables long-term preservation of the printed records
Compact and lightweight for portability and installation anywhere
Interval printing mode for printing weighing data at set intervals
Chart printing mode for printing time-series variations of weighing data
Dump printing mode to receive and print GLP/GMP/GCP/ISO compliant output from the balance/scale
Performs and prints the results of statistical calculation including standard deviation
Prints an ID number set for the printer at any time
Dust-free paper (AX-PP173-S) available for use in clean rooms
Two types of RS-232C cables (D-Sub 25P and D-Sub 9P) provided as standard to connect to balances/scales with different interfaces*
Comes with an AC adapter as standard
Receives a print, paper feed, print statistical calculation results, print total, re-zero, or weighing data request command from the optional foot switch (AX-SW128)
* The cables can be changed to either a DIN or current loop cable at time of order.
Specifications
Character specifications | 7 × 9 dots, 1.6 (W) × 3.2 (H) mm |
Printing speed | Approx. 1.6 lines/second |
Paper feeding speed | Approx. 4 lines/second |
Number of characters printed | 24 characters/line |
Printer paper width | 57.5 mm |
Operating environment | 0 to 40 ˚C/32 to 104 ˚F, 35 to 85%RH (no condensation) |
Storage environment | −20 to 60 ˚C/−4 to 140 ˚F, 10 to 90%RH (no condensation) |
Interface | RS-232C (D-Sub 9P, male) / Current loop (DIN) |
Power supply | AC adapter |
Size / weight | 174 (W) × 141 (D) × 87 (H) mm / approx. 500 g |
Standard accessories | Ink ribbon (1 pc), plain printer paper (1 roll), AC adapter, AC adapter label, instruction manual, two RS-232C cables (D-Sub 25P and D-Sub 9P)* |
* The cables can be changed to either a DIN or current loop cable at time of order
Accessories
AX-PP137-S : Plain printer paper (10 rolls)
AX-PP173-S : Dust-free printer paper (10 rolls)
AX-ERC-22B-S : Ink ribbon (5 pcs)
AD1682 : Rechargeable battery unit*
AD-8529PC-W : Bluetooth converter for PC
AD-8529PR-W : Bluetooth converter for printer
AX-KO4454-010 : Tabletop breeze break
