RIXEN

RIXEN VF-5205 เครื่องวัดความเร็วลม Air Velocity / Flow / Differential Manometer

รหัสสินค้า

VF-5205

฿22,900.00(ไม่รวมภาษี)

ภาพรวม

RIXEN VF-5205 เครื่องวัดความเร็วลม Air Velocity / Flow / Differential Manometer ออกแบบมาสำหรับการใช้งานด้าน HVAC, วิศวกรรมอุตสาหกรรม, ห้องคลีนรูม, ระบบระบายอากาศ และงานตรวจสอบระบบลมต่าง ๆ สามารถเลือกหน่วยวัดความดันได้ถึง 8 หน่วย เช่น Pa, mmH₂O, inH₂O เป็นต้น มีมาตรฐานป้องกันฝุ่นและน้ำระดับ IP65

เพิ่มคำถาม

Air Velocity / Flow / Differential Manometer

Applications : Clean room, Compression cooling systems, Air filter monitoring, Pumps, Fan control, Pneumatic controls, Hospital, Duct airflow, HVAC ... etc.

จุดเด่น

  • รองรับการวัด Air Velocity / Flow / Differential Manometer
  • วัดค่า Differential Pressure ได้อย่างแม่นยำ
  • เลือกหน่วยวัดความดันได้ถึง 8 หน่วย
  • ความแม่นยำสูง ±0.25% ของช่วงการวัด Full Scale
  • ปรับค่า ZERO และช่วงวัดได้ละเอียดด้วยฟังก์ชัน Fine ZERO และ SPAN
  • รองรับการเชื่อมต่อข้อมูลได้ผ่าน USB และ RS-232
  • หน้าจอ LCD ขนาดใหญ่ พร้อมไฟ backlighting ที่มองเห็นชัดแม้ในที่มืด
  • ฟังก์ชัน Data Hold และ ปิดเครื่องอัตโนมัติ (Auto Power Off)
  • มาตรฐานป้องกันฝุ่นและน้ำระดับ IP65
  • รับรองคุณภาพตามมาตรฐาน CE และ RoHS
RIXEN VF-5205 เครื่องวัดความเร็วลม Air Velocity / Flow / Differential Manometer

ภาพด้านบน : แสดงลักษณะ Air Velocity / Flow / Differential Manometer รุ่น VF-5205

RIXEN VF-5205 เครื่องวัดความเร็วลม Air Velocity / Flow / Differential Manometer

ภาพด้านบน : แสดงลักษณะ Air Velocity / Flow / Differential Manometer รุ่น VF-5205

ช่วงการวัด

  • Air Velocity (via Pitot tube) : 400 m/s, 78,730 FPM/(ft/min), 1,440 Km/h, 777.60 Knots, 894.80 MPH
  • Air Flow : 3,276,000 CFM, 227,300 CMM
  • Temperature : 0 to 60℃

Power Supply

ใช้งานร่วมกับแบตเตอรี่ : 9V battery x 1 or AC Adaptor (option)

ขนาดเครื่อง

  • ตัวเครื่อง : 150 × 75 × 28 mm
  • น้ำหนักรวม : 250 g (battery included)

อุปกรณ์ที่มาในชุด

  • VF-5205 x 1
  • Battery x 1
  • Pouch case x 1
  • Operation manual x 1

อุปกรณ์เสริม

  • VF-P0808
  • VF-S0552
  • VF-C0553
  • RS-232
  • AC Adaptor

ข้อมูลจำเพาะ

  1. Resolution
  2. Area: 0.01 ft² / 0.001 m² *
    Air Flow: 1 CFM / 1 CMM
    Temperature: 0.1°C (0.1°F)
    Air Velocity: 0.1 m/s, 1 FPM, 0.1 Km/h, 0.1 Knots, 0.1 MPH
    Differential Pressure: 10 Pa, ±0.001 PSI, ±0.1 mbar, 0.001 bar, 1 mmH₂O, 0.1 inH₂O, 0.1 mmHg, 0.001 inHg
  3. Accuracy (at 25°C)
    ±0.25% F.S, TEB < 1%
    *TEB: Total Error Band
  4. Area Setting
    Max. 9.289 m² / 99.99 ft² (For Air Flow measurement)
    *Area: Pipeline Cross-sectional area.
  5. Measurement Unit
    Pipeline Cross-sectional area: ft², m²
    Temperature: °C, °F
    Air Flow: CFM, CMM (VF-5204+ / VF-5205+)
    Air Velocity: m/s, FPM (ft/min), Km/h, Knots, MPH (VF-5204+ / VF-5205+)
    Differential Pressure: Pa, PSI, mbar, bar, mmH₂O, inH₂O, mmHg, inHg
  6. Media Compatibility
    Dry air or non-corrosive gases and liquids
    Display Functions
    Digital LCD display: Differential Pressure, Air Velocity, Air Flow, Temperature, Measurement Unit
    Sampling Rate
    Approx. 0.5 sec.
    Output Signal
    Digital Output: RS-232 / Modbus RTU protocol
    (Differential Pressure, Air Flow, Air Velocity, Temperature, Max., Min., Avg. simultaneously)
    Temperature Compensation
    0 ~ +60°C (+32°F ~ +140°F) Auto.
  7. Main Functions
    IP65 water and dust proof, Air Flow / Air Velocity / Wind Pressure measurements, Fine ZERO & SPAN adjustments, ZERO setting, Max./Min./Avg. values, Data hold, Switchable °C/°F, USB / RS-232 output, LED backlight, Auto / Manual shutdown, Fine Area adjustment
    Baud Rate
    57600
  8. Operating Environment
    -10 ~ +60°C (+14 ~ 140°F), 0 ~ 95% RH non-condensing
    Power Supply
    One 9 V battery or AC Adapter (optional)
    Dimensions / Weight
    150 (L) × 75 (W) × 28 (D) mm (5.91 × 2.96 × 1.11 inches), excluding pressure hose connector Approx. 250 g (battery included)
    Approvals
    RoHS, CE, IP65
    Standard Accessories
    Instrument (VF-5204 or VF-5205), Battery, Pouch case, Operation manual
    Optional Accessories
    VF-P0808
    VF-S0552 Silicon Tube (red/blue), standard 1M
    VF-C0553 Plastic carrying case
    RS-232 Interface cable
    AC Adapter TU-6019 (AC100V ±10%) / TU-6029 (AC220V ±10%)
